Auto Dialing System in Re Area
Product Details:
Product Description
The Loading Coil Joint manufactured by Epsilon consists of two numbers of Loading Coils of 88 mH or 118 mH assembled inside a brass tube for loading of 4 quad cables. The coils are potted with epoxy compound and lid is sealed after taking the leads for wiring. This joint is meant for use with thermo shrinkable sleeves. Each type has been designed to have a very good insulation between the windings and also between the windings and the case. They can easily withstand a voltage of 2KV (r.m.s) 50 Hz between the windings and the case.
88mH
118mH
| 1. | Dielectric Strength | : | 2000V (rms) 50Hz for 1 min |
| 2. | Insulation resistance at 500 V DC | : | 30, 000M Ohms after 1 min |
| 3. | Inductance series aiding | : | 88mH ± 1.5 % / 118mH ± 1.5% |
| 4. | Inductance series opposing | : | < 0.54 mH |
| 5. | Difference in Inductance between windings | : | Within 0.088mH / 0.1mH |
| 6. | Effective Resistance 800Hz | : | < 4.8 Ohms / < 8.0 Ohms |
| 7. | D.C. Resistance | : | < 3 Ohms / < 4.0 Ohms |
| 8. | Difference in Resistance between windings | : | < 0.1 Ohms |
| 9. | Hysterisis | : | < 3.5658 Ohm / mA / Henry |
| 10. | Near and Cross talk at 800 Hz | : | More than 92 db |
